Frequency Inverter
VH6 / VH6S Fully functional closed-loop vector Frequency inverter

Type : VH6-4022-B
Power : 22 Kw
Input voltage : Three phase 340~420V, 50Hz/60Hz
Output Voltage : 0~380V 3 Phase
Output Frequency : The maximum output frequency to 1000Hz for asynchronous motors and 600Hz for synchronous motors
Input current : 46.5 A
Output current : 45 A

Control motor type : VH6 for Asynchronous motor & VH6S for synchronous motor
Control mode : VF control mode (VVF), No speed sensor vector control (SVC), Vector control with speed sensor ( FVC)
Control terminal : Slot card system, General slot A
Slot A : I/O 1CH RS485 + 2CH AI + 1CH AO + 4CH bipolar input + 1CH YT, 1CH YR
Slot B : I/O 1CH AI + 1CH AO + 3CH bipolar X input + 1CH YT + 1CH YR)
Slot C : CANopen communication card / EtherCAT communication card
Slot D : Simple incremental encoder PG card
