Frequency Inverter
Seri : Economy Open Loop Vector Inverter

Type : VH1-20P7-B
Power : 0.75 Kw
Input voltage : Single phase 220V, 50Hz/60Hz
Output Voltage : 0~input voltage 3 Phase
Output Frequency : 0~600Hz
Output current : 4 A

Control motor type : Asynchronous motor
Control performance : V/F control (VVF), Vector control
Control terminal input : Digital input channel Up to 5 Ch, support NPN and PNP input
Control terminal output : 1 Ch Transistor + 1 Ch Relay
