AC Servo Drive

Drive : DS5L1-21P0-PTA
Power : 1 KW
Input power supply : Single / Three Phase ( 200-240V )
Output current : 6A
Dynamic brake : √
Digital input : 5 Ch
Digital output : 3 Ch
Port : RS232, RS485
Pulse : 5V / 24V
Encoder resolution : 17/23bit
Built-in brake resistor : 45Ω 80W
External brake resistor : 35-75Ω 800W
