AC Servo Drive

Type : DS5L1-20P4-PTA
Power : 0.4 KW
Input power supply : Single / Three Phase ( 200-240V )
Output current : 2.8A
Dynamic brake : x
Digital input : 3 Ch
Digital output : 3 Ch
Port : RS232, RS485
Pulse : 5V / 24V
Encoder resolution : 17/23bit
Built-in brake resistor : x
External brake resistor : 80-100Ω 200W
